Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display
Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display
Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display
Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display
  • Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display
  • Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display
  • Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display

Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display

Model: WF1852T
CPU: RK3288
OS: Android 5.1/6.0/8.1
Brightness: 250cd/m2
Screen Size: 18.5 Inch
Contact Us
2GB
RAM
16GB
ROM
2.0M/P
Camera
2*3W
Speaker
Specifications
Payment & Shipping Terms
Product Description
Specifications
Model: WF1852T
CPU: RK3288
OS: Android 5.1/6.0/8.1
Brightness: 250cd/m2
Screen Size: 18.5 Inch
RAM: 2GB
ROM: 16GB
Camera: 2.0M/P
Speaker: 2*3W
High Light:

Android 5.1 Wall Mounted Digital Signage

,

Android 8.1 Wall Mounted Digital Signage

,

Android 8.1 touch screen advertising player

Payment & Shipping Terms
Minimum Order Quantity: 1 Piece
Price: Negotiable
Packaging Details: Single item, standard packing (57cm*17cm*46cm, 5KG)
Delivery Time: 7-20 work days
Payment Terms: T/T
Supply Ability: 150,000 Pieces per Month
Product Description

Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display



Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display 0






Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display

Appearance characteristics

1.Wall Mount: Bracket is optional for desktop placement of the device;Equipped with wall mounting bracket, support portal or landscape installation.

2. Original A + screen:Offers exceptionally smooth and crisp viewing experience due to its 1920 x 1080 full HD resolution

3. Lightweight fuselage: easy to install

4. Cooling hole: The fuselage has its own cooling holes to ensure that the machine can continue to operate, effectively reduce the damage caused by high temperature to the machine, and greatly prolong the service life of the machine.

Use Scenarios

  1. Supermarket advertising: Display product details, prices, and other information; advertising in elevators, and more.

  2. Medical settings: Display doctor information in the clinic and corridor, as well as registration information.

  3. Fitness centers: Display exercise information, such as heart rate and speed, record exercise data, and show tutorial videos for various exercises.

  4. Food and beverage industry: Display product information for milk tea shops and other food establishments, show advertising, play videos of food production processes, and display corporate chain examples.

Software system

Our machine has a powerful Quad-core processor, enabling it to run various applications smoothly. It also offers different memory configurations to meet different needs. We offer two versions: the standard configuration with RK3288 2+16G Android 8.1 system (with Android 5.1/6.0/8/9.1/10.1/11 available) and the high version with RK3399 Android 9.0 (with Android 7.1/9.0/10.0/11 available). Additionally, we also offer an optional untouchable version for applications that don't require touch interaction.

Hardware interface:

1. Interface: sd card, usb, serial port, headphone jack, OTG port, rj45

2. Speaker:2*3W

3. Mic

4. POE part is optional









System
CPU
RK3288, Quad-core cortex A17
RAM
2GB
Internal memory
16GB
Operation system
Android 5.1/6.0/8.1/9.0
Touch screen
10-Point capacitive touch




Display
Panel
18.5" LCD panel
Resolution
1366*768
Display mode
Normally black
Viewing angle
85/85/85/85(L/R/U/D)
Contrast ratio
800
Luminance
250cd/m2
Aspect Ratio
16:9

Network
WiFi
802.11b/g/n
Ethernet
10M/100M ethernet
Support BT
BT 4.0




Interface
Card slot
SD card, support up to 32GB
USB
USB host*3
USB
Mini USB OTG
RJ45
Ethernet interface
Power jack
DC power input
Earphone
3.5mm earphone


Media play
Video format
MPEG-1, MPEG-2, MPEG-4, H.265, H.264, VC-1, VP8, etc., support up to 4K
Audio format
MP3/WMA/AAC etc.
jpeg




Other
VESA
75x75mm
Speaker
2*3W
Microphone
yes
Camera
Front camera, 2.0M/P
Working temp
0--40 degree
Certificates
CE, FCC, RoHS
Language
Multi-language

Accessories
Adapter
Adapter, 12V/3A
User manual
yes





Product photos




Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display 1

Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display 2Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display 3Android 8.1 Wall Mounted Digital Signage Quad Core Touch Screen Advertising display 4



FAQ


1. What is your product packaging solution? Is it reliable?
The package is a reliable packaging contains the quality product which has passed inspections and drop test. We guarantee to deliver your goods in good condition.



2. What is your modes of transportation in logistics? What’s the delivery charge and delivery date?
Our mode of transportation mainly include express, sea and air shipments, and the delivery charge is calculated based on your address and the product quantity. All products can be delivered within 7-10 days if we have stock. If you have any customization requirements, please contact us for confirmation. Our strong R&D team can meet your special needs in time.



3. Could you introduce your company and products?
Production and sales of Android tablets, digital signage, advertising machines, and Android all-in-one. Founded in 2008, it is located in Shenzhen, with a factory area of 10,000 square meters and more than 300 employees. We have 13 years of experience in touch screen development and manufacturing to achieve a daily output of 5000pcs and an annual shipment of more than 1 million units worldwide. Our products are sold in more than 30 countries and regions. For more product information, please contact our sales manager online.
